Single Layers |
|||||
|
Cable Types |
Fiber Count(Max) |
Diameter(mm) |
Weight(kg/km) |
RTS(KN) |
Short Circuit(kA2s) |
|
OPGW-81[73.9;43.6] |
24 |
12.5 |
488 |
73.9 |
43.6 |
|
OPGW-86[76.8;49.51 |
24 |
12.8 |
510 |
76.8 |
49.5 |
|
OPGW-103[93.8;68.9] |
24 |
13 .8 |
611 |
93.8 |
68.9 |
|
OPGW-85[76.8;46.8] |
32 |
12.8 |
509 |
76.8 |
46.8 |
|
OPGW-85[50.5;54.5] |
32 |
12.8 |
445 |
50.5 |
54.5 |
|
OPGW-112[106.7;80.0] |
36 |
14.7 |
688 |
106.7 |
80 |
|
OPGW-112186.0:90.3] |
48 |
14.7 |
627 |
86 |
90.3 |
|
OPGW-112[62.7;104.5] |
48 |
14.7 |
498 |
62.7 |
104.5 |
|
OPGW-122[65.6;123.9] |
48 |
15.2 |
534 |
65.6 |
123.9 |
|
OPGW-132[121.0;108.7] |
60 |
16 |
810 |
121 |
108.7 |
|
OPGW-132[63.9;148.0] |
60 |
16 |
545 |
63.9 |
148 |
|
OPGW-135 [99.8;132.2] |
72 |
16.3 |
751 |
99.8 |
132.2 |
|
OPGW-146 [109.0;154.9] |
96 |
17.1 |
813 |
109 |
154.9 |
|
Double Layers |
|||||
|
Cable Types |
Fiber Count(Max) |
Diameter(mm) |
Weight(kg/km) |
RTS(KN) |
Short Circuit(kA2s) |
|
OPGW-174[101.0;247.7] |
24 |
17.7 |
744 |
101 |
247.7 |
|
OPGW-244[141.2;479.7] |
24 |
20.7 |
1030 |
141.2 |
479.7 |
|
OPGW-249[1470:501.4] |
48 |
21.1 |
1065 |
147 |
501.4 |
|
OPGW-207[121.8;348.1] |
48 |
19.4 |
892 |
121.8 |
348.1 |
|
OPGW-233[135.8;441.9] |
60 |
20.6 |
999 |
135.8 |
441.9 |
|
OPGW-289 [166.4:675.0] |
72 |
22.9 |
1246 |
166.4 |
675 |
|
OPGW-314 [158.7;826.4] |
96 |
24 |
1277 |
158.7 |
826.4 |
OPGW cables are used power transmission, communication, and lightning protection.It could replace traditional static / shield / earth wires on overhead transmission lines with containing optical fibers which can be used for telecommunications purposes. It is suitable for high-voltage/ultra-high-voltage lines in intercity or cross-country projects that need both communication and grounding functions overlong distances.
